Agriculture Wheels for front tractors, wagons, balers, spreaders, seeders, irrigation systems and feed yard scrapers. Available in both Cream and White finishes. Cream Wheels are available in standard offset/backspace with select sizes available in reversible styles. White Wheels are standard offset/backspace only.
| SKU | Size | Bolt Pattern | Offset | Rear Spacing (in) | Center Bore (in) | Rated load (lb) | Finish | Weight (lb) | Additional Information |
|---|---|---|---|---|---|---|---|---|---|
| 9819306014 | 16.5x8.25 | 8x8.0 | 6.0150 | Cream | 35 | ||||
| 9819311014 | 16.5x9.75 | 8x8.0 | 6.0150 | Cream | 42 | ||||
| 1519288038 | 15x5 | 4x5.0 | 3.6350 | Cream | 23 | ||||
| 1519293038B | 15x6 | 6x6.0 | 4.6380 | Cream | 21.5 | ||||
| 1519294038B | 15x8 | 6x6.0 | 4.6380 | Cream | 28.1 | ||||
| 1519299038B | 15x8 | 8x8.0 | 6.0150 | Cream | 27.2 | ||||
| 1519300038B | 15x10 | 8x8.0 | 6.0150 | Cream | 32.7 | ||||
| 1529714038B | 15x8 | 6x6.0 | 4.6380 | Cream | 34.4 | ||||
| 1619296038B | 16x6 | 6x6.0 | 4.6280 | Cream | 31.7 | ||||
| 1619301038B | 16x8 | 8x8.0 | 6.0150 | Cream | 32.9 | ||||
| 1529713038B | 15x5 | 6x6 | 4.6380 | Cream | 21.3 | ||||
| 1529771038B | 15x6 | 6x6 | 4.6380 | Cream | 23.9 | ||||
| 1429722023B | 14x6 | 6x6 | 4.6380 | White | 21.1 | ||||
| 1519288038B | 15x5 | 4x5 | 3.6350 | Cream | 21.4 | ||||
| 1519295023B | 15x10 | 6x6 | 4.6380 | White | 32.7 | ||||
| 1519295038B | 15x10 | 6x6 | 4.6380 | Cream | 32.7 | ||||
| 1519300023B | 15x10 | 8x8 | 6.0200 | White | 31.9 | ||||
| 1526074038B | 15x10 | 8x8 | 6.0200 | Cream | 37.8 | ||||
| 1526848038B | 15x8 | 6x6 | 4.6380 | Cream | 34.1 | ||||
| 1526859038B | 15x8 | 8x8 | 6.0200 | Cream | 33.3 | ||||
| 1619297038B | 16x8 | 6x6 | 4.6380 | Cream | 33.3 | ||||
| 1619298038B | 16x10 | 6x6 | 4.6380 | Cream | 37 | ||||
| 1619302023B | 16x10 | 8x8 | 6.0150 | White | 36.1 | ||||
| 1619302038B | 16x10 | 8x8 | 6.0150 | Cream | 36.1 |
| SKU | Size | Bolt Pattern | Offset | Rear Spacing (mm) | Center Bore (mm) | Rated load (kg) | Finish | Weight (kg) | Additional Information |
|---|---|---|---|---|---|---|---|---|---|
| 9819306014 | 16.5x8.25 | 8x8.0 | Cream | 16 | |||||
| 9819311014 | 16.5x9.75 | 8x8.0 | Cream | 20 | |||||
| 1519288038 | 15x5 | 4x5.0 | Cream | 11 | |||||
| 1519293038B | 15x6 | 6x6.0 | 117.8052 | Cream | 9.7 | ||||
| 1519294038B | 15x8 | 6x6.0 | 117.8052 | Cream | 12.7 | ||||
| 1519299038B | 15x8 | 8x8.0 | 152.7810 | Cream | 12.3 | ||||
| 1519300038B | 15x10 | 8x8.0 | 152.7810 | Cream | 14.8 | ||||
| 1529714038B | 15x8 | 6x6.0 | 117.8052 | Cream | 15.6 | ||||
| 1619296038B | 16x6 | 6x6.0 | 117.5512 | Cream | 14.4 | ||||
| 1619301038B | 16x8 | 8x8.0 | 152.7810 | Cream | 15 | ||||
| 1529713038B | 15x5 | 6x6 | 117.8052 | Cream | 9.7 | ||||
| 1529771038B | 15x6 | 6x6 | 117.8052 | Cream | 10.9 | ||||
| 1429722023B | 14x6 | 6x6 | 117.8052 | White | 9.6 | ||||
| 1519288038B | 15x5 | 4x5 | 92.3290 | Cream | 9.7 | ||||
| 1519295023B | 15x10 | 6x6 | 117.8052 | White | 14.9 | ||||
| 1519295038B | 15x10 | 6x6 | 117.8052 | Cream | 14.9 | ||||
| 1519300023B | 15x10 | 8x8 | 152.9080 | White | 14.5 | ||||
| 1526074038B | 15x10 | 8x8 | 152.9080 | Cream | 17.1 | ||||
| 1526848038B | 15x8 | 6x6 | 117.8052 | Cream | 15.5 | ||||
| 1526859038B | 15x8 | 8x8 | 152.9080 | Cream | 15.1 | ||||
| 1619297038B | 16x8 | 6x6 | 117.8052 | Cream | 15.1 | ||||
| 1619298038B | 16x10 | 6x6 | 117.8052 | Cream | 16.8 | ||||
| 1619302023B | 16x10 | 8x8 | 152.7810 | White | 16.4 | ||||
| 1619302038B | 16x10 | 8x8 | 152.7810 | Cream | 16.4 |
*indicates Standard/Reverse for Offset and Backspace
